P-30 Short tracks for trapezoidal sheet metal roofs PV-Mounting

P-30 Application
on walkable trapezoidal sheet metal roofs with sheet metal outer skin.

Requirement - Trapezoidal sheet metal with a minimum sheet thickness of 0,5 mm steel / 1,00 mm aluminum
Material P-30: ENAW 6063 permissible tensile load of the material P-30 Profile 1,00 KN

P-30 Advantages

• Good static load distribution
• This type of installation reduces the suction effect on the outer skin of the roof covering by the weight of the PV system.
• Fastened with thin sheet screws or blind rivets approved by the building inspectorate.
• Only two components required for installation.
• No need to transport long profile bars -
• Coordinated with the bead spacing of the profile sheets.
• The profile sections are pre-drilled and sealed with sealing tape.

Technical data

• Art.Nr.: P-30-230-180 / Mounting profile P-30, length 230mm / incl. EPDM seal glued / perforated on bead spacing 180 mm
• Art.Nr.: P-30-260-207 / Mounting profile P-30, length 260mm / incl. EPDM seal glued / perforated on bead spacing 207 mm
• Art.Nr.: P-30-300-250 / Mounting profile P-30, length 300mm / incl. EPDM seal glued / perforated on bead spacing 250 mm
• Art.Nr.: P-30-340-280 / Mounting profile P-30, length 340mm / incl. EPDM seal glued / perforated on bead spacing 280 mm
• Art.Nr.: P-30-400-333 / Mounting profile P-30, length 400mm / incl. EPDM seal glued / perforated on bead spacing 333 mm

Accesories

• Art.Nr.: BN-48-12 / Blind rivets Alu/A2 Ø 4,8x12 (Pre-drill with 5.00mm)
• Art.Nr.: 2006 / Screw thin sheet/ 4,5x25 A2 SW 8 EPDM Ø 14mm

• Art.Nr.: MMK-xxx-xxx / Module middle clamp
• Art.Nr.: MEK-xxx-xxx / Module end clamp

•

  BN-48-12

•

  2006

•

  MMK

•

  MEK

Mounting tools
Drill / Drill bit 5.0 mm / Riveting tool / Alternative - Screw thin sheet SW 8

Mounting

1. Roof layout depends on module dimensions
2. Align the first row using a chalk line.
3. P-30 Place the holder in position, pre-drill with sheet metal drill Ø 5,00 mm and fix it with 4 blind rivets. Alternatively, the fastening can also be carried out with the thin sheet screw without pre-drilling.
4. Place the next rows using a wooden template. After 10 rows, check the direction again with a string.

P-30 Short track examples

Example 1

DICONAL^® P-30 Short tracks.

Example 2

DICONAL^® P-30 Short tracks.

Example 3

DICONAL^® P-30 Short tracks.

Example 4

DICONAL^® P-30 Short tracks.

Trapezoidal sheet alternative mounting solutions

Sliding support GH

DICONAL^® Sliging support GH für nicht begehbare Trapezblechdächer.

Standing seam

Clamps for standing seam roofs with premounted connection to the DICONAL^® PV mounting system.

Kalzip^® clamp

For aluminum standing seam roofs, the combination of profile interface and Kalzip^® clamp is the perfect solution for framed modules.

Hanger bolts

DICONAL^® hanger bolts serve as fastening in the roof substructure when the roof covering does not provide sufficient stability.
